PROLIGHTS ECLCYCLORAMA
LIGHT SOURCE
Source: 170W RGB + Warm White
Luminous flux: (with 80°x40° filter on board) 13’896lm @full
Lux: @1 m to wall and 1,5 m height @ full (with standard filter) 625 lx – (with 40° filter) 1’530 lx – (with 10°x60° filter) 1’590 lx – (with 30°x60° filter) 1’690lx
CRI: 93 @3200K; 91 @5600K
R9: 91 @3200K; 95 @5600K
TLCI: 87 @5600K
TM30 Rf: 88.8 @5600K
TM30 Rg: 107.4 @5600K
Source life expectancy: > 50000H
OPTICS
Beam angle: (HxV) 80°x40°
Additional optics: see available accessories
COLOUR SYSTEM
Colour mixing: RGB + Warm White
CTC: CTC control, + / – green correction, Tungsten emulation
White presets: 2800K – 6500K
Colour wheel: virtual colour wheel with macros
DYNAMIC EFFECTS
Control Resolution: 16bit dimmer, colours
Special features: linear crossfade channel from any white to any colour; virtual CTO on colours
BODY
Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)
Body: sturdy die-cast aluminium body
Body colour: black
Other: +/- 8° angle adjusting
CONTROL
Protocols: DMX512, RDM, Art-Net, sACN, W-DMX
W-DMX: included, wireless solution receiver
RDM: RDM ready for remote monitoring and settings
Display: Graphic User Interface
Firmware upgrade: yes, via USB – DMX interface (UPBOX1) not included
ELECTRONICS
Dimmer curves: selectable dimming modes available
Strobe / shutter: 1 – 30 Hz, electronic
Display battery: self-charging battery backup
Operating temperature: -10° ~ +45°
LED Control: flicker free frequency with adjustable PWM
Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
Mains power supply: 100-240 V – 50/60 Hz
Max power consumption: 400W
Power factor: >0,94
PHYSICAL
Cooling: heat sink without fan
Suspension and fixing: any position with quick-lock omega brackets
Signal connection: Amphenol XLR 5p IN/OUT connectors
Data connection: RJ45 IN/OUT
Power connection: Seetronic powerCON waterproof IN/OUT connectors
IP rating: IP20
Dimensions (WxHxD): 500x119x148mm / 19.69”x4.69”x5.83”
Weight: 5kg
